X2 EV Charger

22kW 3 Phase EV Charger

$1,499.00 inc. GST

Add to cart   View Spec Sheet

Product Information

Overview

SV-EVX2-22LW-3P-5M

Offering a remarkable 22kW of charging capacity, this three phase EV charger is compatible with all EV car models. This charger ensures safety while catering specifically to the Australian market. Boasting a high-quality construction with a generous three-year warranty, it offers effortless installation by a licensed electrician. With an IP65 rating and IK10 durability, it features a Type 2 plug and comes complete with a 5m cable for added versatility. Additional back plates and cover accessories, allow you to prepare for additional EV charger installations, without having to install the actual units reducing the costs of set up for future proofing or fleet preparation. OCPP 1.6J and OCPP 2.0 protocol is already built in ready to integrate with your management software or app over WiFi, LAN, or the internal 4G sim slot. RFID and MODBUS available on request.

Find an installer

I still need help

Features

Compatible with all Australian EV cars

Safe & easy to use

IP65 & IK10

Level 2.5 charging

Type 2 Plug

What's in the box?

1x EV charger with 5m cable

1x User manual

1x Mounting template

4x M6 expansion

4x TS3 x16 screws

3x Sealing plug

1x Allen wrench

2x Strain relief

5x Ferrules

Tech Specs

Max Charging Power

Max output 22KW

Colour

Black

Mounting Method

Wallmount

Input

400Vac±10% 3 Phase

Weight

6.8Kg

Dimensions

345 x 192 x 149mm

Earth Leakage Current (mA)

DC6mA

Operating Current @ 240V (A)

Max 32A

IP Rating

IP65

IK Rating

IK10

Temperature Range

-30°C to +50°C


Product Cover

Optional Accessories …
