X1 EV Charger

7kW Single Phase EV Charger

$799.00 inc. GST

Add to cart   View Spec Sheet

Product Information

Overview

SV-EVX1-7T-1P

Designed for Australians, this single phase EV charger boasts a sleek, compact design, perfect for discreet residential installation. Compatible with all EV car models, ensuring a safe and reliable charging experience. It boasts high-quality construction backed by a three-year warranty. With easy installation by a licensed electrician, the charger operates on a single-phase power supply, making it an ideal choice for home charging needs. It carries an IP54 rating for weather resistance and an IK08 durability rating. Featuring a convenient Type 2 outlet, it allows users to effortlessly plug in the 5m cable *sold separately (or any other Type 2 cable when needed). Enjoy seamless charging without compromising on style and convenience.. Automated load management can be enabled by adding on the CT Clamp accessory*. The EVX1 can even be internally adjusted from 2.2-7.4kW during installation to reduce its maximum output to meet any local requirements.

Find an installer

I still need help

Features

Compatible with all Australian EV cars

Easy & safe to use

IP54 & IK08

Level 2 charging

Type 2 Plug

What's in the box?

1x EV Charger

1x User manual

1x Mounting template

4x Φ10 Expansion Screws

4x M6 Screws

2x M4 Screws

2x M3 Screws

1x Strain relief

Tech Specs

Max Charging Power

7KW

Colour

Black

Mounting Method

Wallmount

Input

240VAC Single phase

Weight

2.9Kg

Dimensions

200 x 115 x 130mm

Earth Leakage Current (mA)

DC6mA

Operating Current @ 240V (A)

Max 32A

IP Rating

IP54

IK Rating

IK08

Temperature Range

-30°C to +50°C


Product Cover

Optional Accessories …
